Digital Bodleian IIIF API Specification (2.0.0)

Download OpenAPI specification:Download

Digital Bodleian Support: digital-bodleian@bodleian.ox.ac.uk

This is the IIIF API Specification for Digital Bodleian. We provide our manifests in both Presentation API v2 (default) and v3 (available via Content Negotiation).

Most URIs are dereferenceable, and are returned with their appropriate JSON-LD @context when de-referenced. The only exception to this are Ranges; this will be addressed in a future update.

The 406 Not Acceptable status code will be returned for requests that apply to a specific IIIF version. For example, Sequences have been removed in v3, so requesting a Sequence ID as a IIIFv3 response will return a 406 Status Code.

Harvesting

You are welcome to harvest our manifests for the purposes of indexing or making our content available in aggregator services. However, if are expecting to harvest a significant number of manifests, we would ask that you get in touch with us and let us know. You can do this by contacting our digital support team, or by adding your e-mail address to the User-Agent string.

We would prefer that you do not download and re-host our images.

Bug Reports

We welcome bug reports. If you are having a problem retrieving or parsing our manifests, or if you find an invalid manifest, please contact us and provide the link to the manifest that does not work.

Manifest

Retrieve a IIIF Manifest

Returns a IIIF Manifest. Clients will receive a Presentation v2.1 manifest by default. Version 3.0 manifests can be returned by sending an Accept header with a value of application/ld+json;profile=http://iiif.io/api/presentation/3/context.json.

Presentation API 3.0 manifests are returned with a partOf key that contains a link to all Collections this manifest is a member of.

path Parameters

manifest_id

required

string <uuid>

Example: b73ca01f-aac8-4916-a7c6-3c8e67939a66

The ID of the Manifest to Retrieve

Responses

Response samples

200

Content type

{"@context": "http://iiif.io/api/presentation/2/context.json",
"@id": "https://iiif.bodleian.ox.ac.uk/iiif/manifest/b73ca01f-aac8-4916-a7c6-3c8e67939a66.json",
"@type": "sc:Manifest"
}

Canvas

Retrieve a dereferenced Canvas Object

Dereferenced Canvases are returned with the within key (v2) or a partOf key (v3) pointing to their parent manifest.

path Parameters

canvas_id

required

string <uuid>

Example: f37dd11c-a243-4b66-9a65-b8d498a114d6

The ID of the Canvas to retrieve

Responses

Response samples

200

Content type

{"@context": "http://iiif.io/api/presentation/2/context.json",
"@id": "string",
"@type": "sc:Canvas"
}

Sequence

Retrieve a dereferenced Sequence object (Presentation v2 Only)

A dereferenced Sequence Object. Note that sequences are only available in v2 manifests, so this will return a 406 status code if it is requested for a v3 manifest. For all manifests we publish there will be only one sequence, the default.

path Parameters

sequence_id

required

string

Example: faeff7fb-f8a7-44b5-95ed-cff9a9ffd198_default

The ID of the sequence

Responses

Response samples

200

Content type

{ }

Annotation

Retrieve an dereferenced Annotation Object

A dereferenced Annotation Object.

path Parameters

annotation_id

required

string <uuid>

Example: f37dd11c-a243-4b66-9a65-b8d498a114d6

The Annotation ID

Responses

Response samples

200

Content type

{ }

AnnotationPage

Retrieve a dereferenced AnnotationPage Object (Presentation v3 Only)

A dereferenced AnnotationPage Object. Note that annotation pages are only available in v3 manifests, so this will return a 406 status code if it is requested for a v2 manifest.

path Parameters

annotation_page_id

required

string

Example: f37dd11c-a243-4b66-9a65-b8d498a114d6

The annotation page ID

Responses

Response samples

200

Content type

{ }

AnnotationList

Retrieve a dereferenced AnnotationList Object (Presentation v2 Only)

A dereferenced AnnotationList Object. Note that annotation pages are only available in v2 manifests, so this will return a 406 status code if it is requested for a v3 manifest.

path Parameters

annotation_list_id

required

string

Example: f37dd11c-a243-4b66-9a65-b8d498a114d6

The annotation list ID

Responses

Response samples

200

Content type

{ }


Retrieve the info.json for an image resource

A IIIF Image API Info Response. Clients will receive a Image API v2.1 response by default. Version 3.0 responses can be returned by sending an Accept header with a value of application/ld+json;profile=http://iiif.io/api/image/3/context.json.

If a request omits the /info.json, the response will be a 307 redirect to /info.json.

path Parameters

image_id

required

string <uuid>

Example: 082d5ad2-ea08-463c-ad50-6d1a0cb01246

The ID of the Image to retrieve

Responses

Response samples

200

Content type

application/json

{"@context": "http://iiif.io/api/image/2/context.json",
"@id": "string",
"@type": "sc:Image"
}

Retrieve an image

Supports the IIIF v2.1 and v3.0 Image API. A full Image API URL might look like:

https://iiif.bodleian.ox.ac.uk/iiif/image/1363b336-260d-4f22-a6cf-4e1320dbb689/800,1400,1550,1950/256,/0/default.jpg

This should return the following image:

path Parameters

image_id required	string <uuid>
required	Full (string) or Array of Arr (integers) Image Region to return. Can be either the keyword `full`, `square`, a comma-separated list of either pixel dimensions, `x,y,w,h`, or percentages of the full image, `pct:x,y,w,h`.
required	Full (string) or Array of Arr (integers) Size of image to return. Supports the following values: `max`: The extracted region is returned at the maximum size available, but will not be upscaled. The resulting image will have the pixel dimensions of the extracted region, unless it is constrained to a smaller size by maxWidth, maxHeight, or maxArea as defined in the Technical Properties section. `^max`: The extracted region is scaled to the maximum size permitted by maxWidth, maxHeight, or maxArea as defined in the Technical Properties section. If the resulting dimensions are greater than the pixel width and height of the extracted region, the extracted region is upscaled. `w,`: The extracted region should be scaled so that the width of the returned image is exactly equal to w. The value of w must not be greater than the width of the extracted region. `^w,`: The extracted region should be scaled so that the width of the returned image is exactly equal to w. If w is greater than the pixel width of the extracted region, the extracted region is upscaled. `,h`: The extracted region should be scaled so that the height of the returned image is exactly equal to h. The value of h must not be greater than the height of the extracted region. `^,h`: The extracted region should be scaled so that the height of the returned image is exactly equal to h. If h is greater than the pixel height of the extracted region, the extracted region is upscaled. `pct:n`: The width and height of the returned image is scaled to n percent of the width and height of the extracted region. The value of n must not be greater than 100. `^pct:n`: The width and height of the returned image is scaled to n percent of the width and height of the extracted region. For values of n greater than 100, the extracted region is upscaled. `w,h`: The width and height of the returned image are exactly w and h. The aspect ratio of the returned image may be significantly different than the extracted region, resulting in a distorted image. The values of w and h must not be greater than the corresponding pixel dimensions of the extracted region. `^w,h`: The width and height of the returned image are exactly w and h. The aspect ratio of the returned image may be significantly different than the extracted region, resulting in a distorted image. If w and/or h are greater than the corresponding pixel dimensions of the extracted region, the extracted region is upscaled. `!w,h`: The extracted region is scaled so that the width and height of the returned image are not greater than w and h, while maintaining the aspect ratio. The returned image must be as large as possible but not larger than the extracted region, w or h, or server-imposed limits. `^!w,h`: The extracted region is scaled so that the width and height of the returned image are not greater than w and h, while maintaining the aspect ratio. The returned image must be as large as possible but not larger than w, h, or server-imposed limits.
rotation required	integer [ 0 .. 360 ] Default: 0 Rotation angle of the returned image, specified in degrees. Only supported in 90 degree increments. Raises a 500 error if the values are less than 0, or greater than 360. All values may be prepended with a `!` to indicate that the image should be mirrored before being rotated.
quality required	string Enum: "default" "color" "grey" "bitonal" Quality of the returned image. `default` is a synonym for `color`. `grey` will return a greyscale version of the image, and `bitonal` a bitonal version.
format required	string Value: "jpg" The only supported return format is `jpg`.

Responses

Collection

Retrieve the top-level IIIF Collection

The top-level IIIF Collection contains a list of all of the sub-collections. Harvesters and crawlers should note that many manifests belong to two or more collections, so using this as an entry point for retrieving all manifests will result in many duplicate records. It is better to use the all collection, which links directly to all manifests, or to individual collections.

Responses

Response samples

200

Content type

{"@context": "http://iiif.io/api/presentation/2/context.json",
"@id": "string",
"@type": "sc:Collection"
}

Retrieve URLs for all IIIF Manifests at the Bodleian

A list of all manifests we publish, sorted by their label. This is a very large result to download.

Responses

Response samples

200

Content type

{"@context": "http://iiif.io/api/presentation/2/context.json",
"@id": "string",
"@type": "sc:Collection"
}

Retrieve a IIIF Collection

Clients may use the top-level Collection endpoint to discover the URIs for all collections we publish.

path Parameters

collection_id

required

string

Example: colleges

The ID of the Collection to Retrieve

Responses

Response samples

200

Content type

{"@context": "http://iiif.io/api/presentation/2/context.json",
"@id": "string",
"@type": "sc:Collection"
}

ActivityStream

Monitor content added to Digital Bodleian

Responses

Response samples

200

Content type

{ }

An individual page of results

path Parameters

page-number

required

string

A page number, formatted as 'page-NNN', where NNN is an integer value for a page, e.g., 'page-0'.

Responses

Response samples

200

Content type

{ }

A de-referenceable individual Activity

While individual activities for update and delete MAY be provided in the future, at present we only publish 'Create' activities

path Parameters

uuid

required

string <uuid>

An identifier of the create activity. In theory this may be any UUID; in practice, since we are only publishing Create activities, this will correspond to the UUID of the created object.

Responses

Response samples

200

Content type

{ }

Discovery

A root-level document advertising browseable IIIF services

A request for the root (https://iiif.bodleian.ox.ac.uk/) will return a JSON document containing links to top-level IIIF resources; namely the top-level collection, and a pointer to the ActivityStreams root. Root requests ("/") will return a 303 Redirect to "/info.json".

Responses

Response samples

200

Content type

{ }
